advantage of our luxury australia expandable container house home

techincal specification

wind load:170km/h
snow load:20cm dry snow
seismic load:7 grade
bearing load:150-200kg/m2

1.frame of expandable container house

expandable container house is modified by flat pack container house,so main container house is one set flat pack container house

the floor of the two expanded parts are made by galvanized tube steel and are connected to main container by bolt

frame of extra veranda,canopy can be also connected by bolt

2.wall&roof of collapsible container house

50mm eps sandwich panel is standard material for wall
optional thickness 75mm,100mm.optional insulation eps,glass wool,rock wool,polyuranthane

2pcs wall of main container,3pcs wall of each expanded parts are pre-made in factory.all around is reinforce with U channel.in this way,installation time will be saved

3.floor

MGO board or fiber cement board works as the bottom floor tile
and PVC tile,carpet or wood floor and be added on top

4.window and door

window:PVC sliding window single glazed/double glazed
aluminum sliding door single glazed/double glazed

interior door:sandwich panel door/steel security door

5.layout

installation process of our expandable container house

1.install the main container frame as flat pack container house

2.link bottom frame of the expanded part the the main container house by bolt

3.install 2pcs wall of main container,3pcs wall of each expanded part

4.install roof of the expanded parts

5.install flashing ,downpipe,gutter
